Part Number |
Status |
Frequency Min |
Frequency Max |
Insertion Loss |
Input/Output VSWR |
Input Power |
LM-0D5G2G-5CW- 54DBM-PP |
Preliminary |
0.5 GHz |
2.0 GHz |
1.0 dB MAXIMUM@ -10 dBm INPUT |
2.0:1 MAX@ -10 dBm INPUT |
5 W CW MINIMUM |
54 dBm (5% DUTY CYCLE, 1 µs PULSE WIDTH) |
LM-10M18G-16-20W- AL-ROHS |
Preliminary |
10 MHz |
18.0 GHz |
2.0 dB Max @ -10 dBm Input Power |
2.0:1 Max @ -10 dBm Input Power |
-10 dBm |
LM-15G17D5G-18-20W- 1KWP-SFF |
Preliminary |
15 GHz |
17.5 GHz |
1.7 dB MAX @ ROOM TEMP |
1.5:1 MAX |
50 dBm 20% DC, 100us PW MAX |
LM-20M15G-100W- 15DBM-NMF |
Preliminary |
20.0 MHz |
15.0 GHz |
2.0 dB MAX @ -10 dBm |
2.0:1 MAX @ -10 dBm Input Power |
100W CW MAX @ -55°C to |
+85°C |
1 KW PEAK MAX +85°C (1us |
Pulse Width. 0.1 % Duty Cycle) 100W ( 1us, 1 % DUTY CYCLE, |
10 KHz) |
100W ( 10us, 0.1% DUTY CYCLE, 100 Hz) |
100W ( 1us, 0. 1 % DUTY CYCLE, 1 KHz) |
100W ( 40us, 10% DUTY CYCLE, 2.5 KHz) |
PSMT-LM-20M6G-100W |
Preliminary |
20 MHz |
6.0 GHz |
0.85 dB |
2.0:1 |
85 WATTS @ 25 DEGREES C |
70 WATTS @ 85 DEGREES C |
LM-150M5G-200CW- 2KWPK-AGAL-NFF |
Active |
150 MHz |
5 GHz |
2.00 dB Max (150 MHz to 300 MHz) |
1.70:1 Max |
200 Watts CW (+53 dBm) Typ |
1.50 dB Max (300 MHz to 5 GHz) |
2 kW Peak Power (+63 dBm) |
|
Typ |
|
(25 µs PW, 5% Duty Cycle) |
LM-2R83R2-316W-20W- PIN |
Preliminary |
2.8 GHz |
3.2 GHz |
0.6 dB Max |
1.5:1 Max |
- |
LM-99R5-316W-20W- PIN |
Preliminary |
9.0 GHz |
9.5 GHz |
1.8 dB Max |
1.9:1 Max |
- |
LM-150M5G-200CW- 2KWPK-AGAL-SMT |
Preliminary |
150 MHz |
5 GHz |
2.00 dB Max. (150MHz to 300 MHz) |
1.70:1 Max |
- |
1.50 dB Max. (300MHz to 5 GHz) |
LM-812-15-25W-SMM |
Active |
8.0 GHz |
12.0 GHz |
1.8 dB Max |
1.7:1 Max |
25 WATTS CW Max |
1.5:1 Goal |
LM-10M62G-20DBM- 1W-24FF |
Active |
10 MHz |
62 GHz |
10 MHz to 18 GHz: 1.5 dB |
10 MHz to 18 GHz: 1.80:1 |
10 Watts Peak Max (20 MHz |
Max |
Max |
to 1 GHz) |
18 to 40 GHz: 2.3 dB Max |
18 to 40 GHz: 2.0:1 Max |
6 Watts Peak Max (4 to 8 GHz) |
40 to 50 GHz: 2.5 dB Typ |
40 to 50 GHz: 2.2:1 Max |
4 Watts Peak Max (12 to 18 GHz) |
50 to 62 GHz: 4.0 dB Typ |
50 to 62 GHz: 3.0:1 Typ |
(PW 1 µs, 1 % Duty Cycle) |
LM-10M2D5G-100CW- 1KWP-SFF-HERM |
Preliminary |
0.01 GHz |
2.5 GHz |
0.5 dB TYP. |
1.3:1 Max |
100 watts CW Max (Notes 1,2), 1 kW peak (1% duty cycle, 1 µs Max pulse width) (Notes 1, 2, 3) |
LM-10M37G-15DBM- 10W-AGAL |
Active |
0.01 GHz |
37.0 GHz |
0.01 to 8 GHz: 1.00 dB Max 8 to 18 GHz: 2.00 dB Max 18 to 30 GHz: 2.70 dB Max 30 to 37 GHz: 4.30 dB Max |
1.8:1 Max |
50 Watts Peak Max (0.02 to 12 GHz) |
40 Watts Peak Max (18 GHz) |
(1 µs Pw, 1% Duty Cycle) |
LM-150M5G-200CW- 2KWPK-AGAL |
Active |
0.15 GHz |
5 GHz |
2.00 dB Max (0.15 to 0.3 GHz) |
1.70:1 Max |
200 Watts CW (+53 dBm) Typ |
1.50 dB Max (0.3 to 5 GHz) |
2 kW Peak Power (+63 dBm) |
|
Typ |
|
(25 µs PW, 5% Duty Cycle) |
LM-10M35G-15DBM- 4W-292FF |
Active |
0.01 GHz |
35.0 GHz |
1.3 - 4.0 dB |
2.0:1 |
25 to 4 Watts CW |
LM-10M40G-15DBM- 4W-AGAL |
Active |
0.01 GHz |
40 GHz |
1 to 3.20 dB |
2.0:1 |
4 - 25 Watts |
LM-10M50G-20DBM- 1W-24FF |
Active |
0.01 GHz |
50.0 GHz |
0.01 to 18 GHz = 1.50 dB Max |
2.01 Max |
10 Watts Peak Max (0.02 to 1 GHz) |
18 to 40 GHz = 2.30 dB Max |
6 Watts Peak Max (4 GHz to 8 GHz) |
40 to 50 GHz = 2.50 dB Max |
4 Watts Peak Max (12 GHz to 18 GHz) |
|
(Pw 1 µs, 1 % Duty Cycle) |
LM-10M50G-18DBM- 4W-24FF |
Active |
0.01 GHz |
50 GHz |
0.01 to 18 GHz: 1.50 dB Max 18 to 40 GHz: 2.20 dB Max 40 to 50 GHz: 3.40 dB Max |
2.0:1 Max |
20 Watts Max |
(Pw 1 µs, 1% Duty Cycle) |
Tested up to 18 GHz (Pw 10 µs, 1% Duty Cycle) |
Tested up to 8 GHz |
16 Watts Max at 18 GHz ( Pw 10 µs, 1% Duty Cycle) |
LM-0R3G8G-14-100W- SFF |
Active |
0.3 GHz |
8 GHz |
2.20 dB Max |
2:1 Max |
- |
LM-26G40G-14-20W- 292FF Rev. B |
Active |
26.5 GHz |
40 GHz |
4.0 dB Max |
2.0:1 |
20 Watts Peak (40% DC / 900 kHz PRF) |
LM-2G4G-15-100W-SFF |
Active |
2.0 GHz |
4.0 GHz |
1.5 dB Max |
2:1 Max |
4 W CW Min @ 85°C. |
1000 W Peak Min @ 85°C (1 µs Pulse Width, 0.1% Duty |
Cycle) |
LM-10M6G-15-2D5W- SFF |
Active |
0.01 GHz |
6.0 GHz (Usable to 10.0 GHz) |
2 dB Max |
1.8:1 Max |
2.5 W (+34 dBm) CW Max Peak Power 3 W (+35 dBm), Pulse 1 µs 1% Duty Cycle |
LM-20M18G-100W- 15DBM-NFM |
Preliminary |
0.02 GHz |
18.0 GHz |
2 dB goal, 2.5 dB max. |
2.0:1 max. (@ -10 dBm Input) |
100 W CW max. |
All Temperatures (-55°C to |
+85°C) |
1 kW Peak (1% Duty Cycle, 1 usec Pulse Width) |
100 W Peak (10% Duty Cycle, 10 usec Pulse Width) |
LM-50M4G-16-1W-SFF |
Active |
0.05 GHz |
4.0 GHz (Usable to 11.0 GHz) |
1.7 dB Max |
1.80:1 Max |
1 W (+30 dBm) CW Max |
(Usable to 4 W Max) |
Peak Power 32 W Peak (+45 dBm), |
Pulse 1 µs, Duty Cycle 0.1% |
LM-910D5-100W- 1KWP-SFM |
Preliminary |
9.0 GHz |
10.5 GHz |
2 dB max. |
2.0:1 max. (At -10 dBm Input) |
100 W CW max. |
All Temperatures (-55°C to |
+85°C) |
1 kW Peak (1% Duty Cycle, 1 usec Pulse Width) |
100 W Peak (10% Duty Cycle, 10 usec Pulse Width) |
LM-10M12G-20-10W- SFF |
Active |
0.01 GHz |
12.0 GHz |
2 dB Max |
2:1 Max |
+40 dBm CW Max Peak Power 100 W, |
Pulse 1 µs 1% Duty Cycle |
LM-10M12G-20-10W- SFF-OPTION-17G |
Active |
0.01 GHz |
17.0 GHz |
2.3 dB Max |
2:1 Max |
+40 dBm CW Max |
Peak Power 100 W, Pulse 1 µs 1% Duty Cycle |
LM-1G2G-19-200W-SFF |
Active |
1.0 GHz |
2.0 GHz |
1.3 dB Max |
2:1 max. |
+53 dBm CW Max (200 W) |
+55 dBm Peak 3 µs Pulse, 10% Duty Cycle (320 W) |
LM-1G18G-15-10W- 500WP-SFF |
Preliminary |
1.0 GHz |
18.0 GHz |
2.5 dB max. |
2.0:1 max. |
10 W CW max. |
LM-300M1G-21-360W- SFF |
Active |
0.3 GHz |
1.0 GHz |
- |
2:1 Max |
+54 dBm CW Max (250 W) |
Peak Power 360 W, Pulse 2 ms, 10% Duty Cycle |
LM-20M20G-18-20WP- 5W-MAH |
Active |
0.02 GHz |
20.0 GHz |
2.5 dB Max |
2.0:1 Max |
20 W Pulsed, 100 µs Pulse |
Width, 10% Duty Cycle, 5 W CW |
LM-218-14-200W-SMF * |
Active |
2.0 GHz |
18.0 GHz |
2.0 dB max. @ Pin = -10 dBm |
2.0:1 max. |
1 W CW |
LM-818-C3-1 |
Preliminary |
8.0 GHz |
18.0 GHz |
1.7 dB typ., 1.9 dB max. |
2.0 max. |
3 W max. |
LM-0D52-C3-1 |
Preliminary |
0.5 GHz |
2.0 GHz |
0.5 dB max. |
1.5 max. |
3 W max. |
LM-28-C3-1 |
Preliminary |
2.0 GHz |
8.0 GHz |
1.0 dB typ., 1.2 dB max. |
2.0 max. |
3 W max. |
LM-2G18G-18-20W- 1KWP-SFF |
Active |
2.0 GHz |
18.0 GHz |
2.6 dB Max (@ -10 dBm Input Power) |
2.01 Max (@ -10 dBm Input Power) |
+43 dBm CW Max |
LM-100M18-2D5W- 12DBM-SFF |
Preliminary |
0.1 GHz |
18.0 GHz |
2.5 dB max. |
2.0:1 max. |
2.5 W CW max. |
LM-3G4G-10-33DBM- 12V |
Preliminary |
3.0 GHz |
4.0 GHz |
0 dB typ. |
2.0:1 max. |
+33 dBm CW |
LM-20M18G-15DBM- QFN |
Preliminary |
0.02 GHz |
18.0 GHz |
2.6 dB max. |
2.0:1 typ. |
+15 dBm CW max. |
LM-9G9R5G-PIN-20W |
Preliminary |
9.3 GHz |
9.5 GHz |
2.0 dB |
2.0:1 max. |
300 W (+54.78 dBm) max. |
Pulse Width 1 TO 13 us Duty Cycle 6% max. |
LM-10M18G-16-20W- AL-OPT8G12G |
Preliminary |
8.0 GHz |
12.0 GHz |
1.8 dB max. |
1.8:1 typ. |
20 W min. |
LM-10M18G-16-20W-AL |
Active |
0.01 GHz |
18.0 GHz |
2.0 dB Max @ -10 dBm Input Power |
2.0:1 Max @ -10 dBm Input Power |
-10 dBm |
LM-20M18G-100W- 15DBM |
Active |
0.02 GHz |
18.0 GHz |
2.60 dB Max @ -10 dBm Input Power |
2.0:1 Max @ -10 dBm Input Power |
100 W CW Max @ -55 °C to |
+85 °C, 1 KW Peak Min |
@ +85 °C (1 µs Pulse Width, 0.1% Duty Cycle) |
100 W (1 µs, 1% Duty Cycle, 10 KHz) |
100 W (10 µs, 0.1% Duty Cycle, |
100 Hz) |
100 W (1 µs, 0.1% Duty Cycle, |
1 KHz) |
100 W (40 µs, 10% Duty Cycle, |
2.5 KHz) |
LM-20M15G-100W- 15DBM |
Active |
0.01 GHz |
15.0 GHz |
1.60 dB Max @ -10 dBm Input Power |
2.0:1 Max @ -10 dBm Input Power |
100W CW Max @ -55°C to |
+85°C |
1KW Peak Min +85°C (1 us Pulse Width, 0.1% duty cycle 100W (1 us, 1% duty cycle, 10 KHz |
100W (10 us,0.1% duty cycle, 100 hz |
100W (1 us, 0.1% duty cycle, 1 KHz) |
100W(40 us, 10% duty cycle, 2.5KHz) |
LM-20M18G-80W- 15DBM |
Active |
0.02 GHz |
18.0 GHz |
2.60 dB Max @ -10 dBm Input Power |
2.0:1 Max @ -10 dBm Input Power |
80 W CW Max @ -55 °C to +85 |
°C |
1 KW Peak min. +85 °C (1 µs Pulse Width, 0.1% Duty Cycle) 100 W (1 µs, 1% Duty Cycle, 10 KHz) |
100 W (10 µs, 0.1% Duty Cycle, |
100 Hz) |
80 W (1 µs, 0.1% Duty Cycle, 1 KHz) |
80 W (40 µs, 10% Duty Cycle, |
2.5 KHz) |
LM-4G5G-1W-SFF |
Preliminary |
4.0 GHz |
5.0 GHz |
1 dB max. |
1.5:1 max. |
1 W max. |
LM-30M2G-5CW-1KWP- SFF |
Active |
0.03 GHz |
2.0 GHz |
0.7 dB goal, 1 dB Max @ 0 dBm Input |
2.0:1 Max @ 0 dBm Input |
5 W CW Min |
1 kW Peak (0.1% Duty Cycle, 1 µs Max Pulse Width) |
LM-4G5G-1W-PIN |
Preliminary |
4.0 GHz |
5.0 GHz |
1 dB max. |
1.5:1 max. |
1 W max. |
LM-4G5G-1W-SFM |
Active |
4.0 GHz |
5.0 GHz |
1 dB max. |
1.5:1 max. |
1 W max. |
LM-8G12G-1R5-SFM |
Preliminary |
8.0 GHz |
12.0 GHz |
1.5 dB max. |
1.8:1 max. |
Average: 1 W max. |
Peak Power: 100 W max. |
PSMT-LM-20M6G |
Preliminary |
0.02 GHz |
6.0 GHz |
1.0 dB max. |
1.4:1 max. |
10 W |
LM-2G6G-3W-SMF |
Preliminary |
2.0 GHz |
6.0 GHz |
1.2 dB max., 1.0 dB goal |
2:1 max. |
3 W |
LM-2G6R5G-3W-SMF |
Active |
2.0 GHz |
6.5 GHz |
1.2 dB max., 1.0 dB goal |
2:1 max. |
3 W |
LM-10M14G-100W- 1KWP-SFF |
Active |
0.01 GHz |
14.0 GHz |
2.0 dB typ. |
2.0:1 Max (@ -10 dBm Input) |
100 W CW Max, 0.01 to 14.0 |
GHz |
All Temperatures (-55 ºC to |
+85 ºC) |
1 KW Peak (1% Duty Cycle, 1 µs Pulse Width |
100 W Peak (10% Duty Cycle, 10 µs Pulse Width) |
LM-10M14G-100W- 1KWP-SFF-OPT17 |
Active |
10 MHz |
7.0 GHz |
2.0 dB Typ |
2.0:1 Max (@ -10 dBm Input) |
100 W CW Max, 1.0 to 7.0 GHz |
All Temperatures (-55 ºC to |
+85 ºC) |
1 KW Peak (1% Duty Cycle, 1 µs Pulse Width |
100 W Peak (10% Duty Cycle, 10 µs Pulse Width) |
LM-10M9G-100CW- 1KWP-SFF |
Active |
0.01 GHz |
9.0 GHz |
2 dB Typ |
2.0:1 Max (At -10 dBm |
100 W CW Max, 0.01 to 8.0 |
input) |
GHz |
|
80 W CW Max at 9.0 GHz 50 W CW Max 0.01 to 9.0 GHz |
|
All Temperatures (-55 °C to |
|
+85 °C) |
LM-2G18G-10-100W- SFF |
Preliminary |
2.0 GHz |
18.0 GHz |
4.0 |
2.0:1 |
1 Watt CW Max. |
LM-30M3G-1-PE2- HERM-292MF |
Preliminary |
0.03 GHz |
3.0 GHz |
1.2 dB max. |
1.5:1 max. |
5 W CW @ +25°C |
LM-400M4G-20CW- 220WP-SFF-PE2 |
Preliminary |
0.4 GHz |
4.0 GHz |
1.2 dB typ. |
1.5:1 typ. |
20 W CW |
LM-0580-10-1W-SHS-1- M |
Preliminary |
0.5 GHz |
8 GHz |
2.0 dB max., 1.5 dB typ. |
2.0:1 max |
1 Watt CW, 100 Watts Peak, 1 us Pulse Width, 0.1% Duty Cycle, Derated to 20% @ 125 ºC |
LM-0R4G5G5G-20W- SFF-OPT400M500M |
Preliminary |
0.4 GHz |
0.5 GHz |
1.0dB typ |
2.0:1 max |
20 Watts CW max, 200W Peak, 10% Duty Cycle, 1uS PW |
LM-10G-3-26DBM-12V |
Active |
10 GHz |
10 GHz |
4.0 dB typ |
2.0:1 |
-45 to +26dBm CW |
LM-1G18G-15-25W- SMF-OPT1G4G |
Preliminary |
1.0 GHz |
4.0 GHz |
1.0 dB |
2.0:1 max |
10 Watts CW |
LM-1G18G-15-25W- SMF-OPT4G8G |
Preliminary |
4.0 GHz |
8.0 GHz |
1.5 dB |
2.0:1 |
10 Watts CW |
LM-1K2G-5CW-SFF- HERM |
Preliminary |
0.001 GHz |
2 GHz |
0.8 dB max. |
1.3:1 max |
5 W CW min. |
LM-1K2G-5CW-SFF- HERM-SM |
Preliminary |
0.001 GHz |
2 GHz |
0.8 dB max. |
1.3:1 max |
5 W CW min. |
LM--218-14-200W-SMF |
Preliminary |
2 GHz |
18 GHz |
2.0 dB Max |
2.0:1 max |
1 W CW |
LM-5D25G5D75G- 18DBM-50W-PP |
Preliminary |
5.25 GHz |
5.75 GHz |
1.0dB max |
1.5:1 max |
50W Peak max @ 40% Pulse |
LM-6D7G7D9G-30W- SMF |
Preliminary |
6.7 GHz |
7.9 GHz |
1.1 dB Max |
1.5:1 max |
30 Watts CW Max |
LM-6G18G-15-10W-SFF- OPT1114 |
Preliminary |
11 GHz |
14 GHz |
- |
- |
20 Watts (43 dBm) |
LM-6G18G-15-10W-SFF- OPT812 |
Preliminary |
8 GHz |
12 GHz |
1.5 dB Typ @ 0dBm |
1.8:1 |
10 Watts CW |
LM-10M2D5G-100CW- 1KWP-SFF-OPT3G3D7G |
Preliminary |
3.0 GHz |
3.7 GHz |
2.0 dB |
1.9:1 |
100 watts CW |
LM-10M2D5G-100CW- 1KWP-SFF-TH |
Preliminary |
0.01 GHz |
2.5 GHz |
0.5 dB |
1.3:1 max |
100 watts CW |
LM-17G18G-10-350W- SFF-VF |
Active |
17 GHz |
18 GHz |
3.0 dB Typ |
1.8:1 typ |
350 Watts, 20usec, 6% Duty Cycle (Peak) |
LM-1G2G-4CW-1KWP- SMF-OPT10M6G |
Active |
0.01 GHz |
6.0 GHz |
2.0 dB Max - Measured 1.68 dB |
2.0:1 Max |
4 W CW |
LM-1G2G-N15-33DBM- 12V |
Active |
1 GHz |
2 GHz |
2.0dB max |
2.0:1 max |
+33 dBm CW max. |
LM-1R2G1R4G-20- 100W-SM |
Preliminary |
1.2 GHz |
1.4 GHz |
0.6 dB |
1.4:1 max |
100 W Peak (1.2 ms Pulse Width, 20% Duty Cycle) |
LM-218-10-1W-SHS-1-M |
Preliminary |
2 GHz |
18 GHz |
2.0 dB max., 1.5 dB typ. |
2.0:1 max |
1 W CW, 100 W Peak, 1 us |
Pulse, 0.1% Duty Cycle Derated to 20% at 125°C |
LM-218-14-200W-SFF- OPT10M18G |
Preliminary |
0.01 GHz |
18 GHz |
2.0 dB max. |
2.0:1 max |
1 W CW |
LM-218-14-200W-SFF- OPT10M20G-SMT |
Preliminary |
0.01 GHz |
20 GHz |
2.0 dB max. |
2.0:1 max |
1 W CW |
LM-218-14-200W-SMF- OPT1114 |
Preliminary |
11 GHz |
14 GHz |
- |
- |
20 Watts (43 dBm) |
LM-218-14-200W-TUB- SFF |
Preliminary |
2 GHz |
18 GHz |
2.0 dB Max |
2.0:1 max |
1 W CW |
LM-2D5G3D5G-12V-SFF |
Preliminary |
2.5 GHz |
3.5 GHz |
3 dB max. |
1.5:1 max |
+30 dBm (1W) CW max. |
LM-32G36G-14-20W- 292FF |
Preliminary |
32 GHz |
36 GHz |
2.0 dB max |
2.0:1 |
20 W (Peak) |
LM-35D5G-14-20W- 292FF |
Active |
35.5 GHz |
35.5 GHz |
3.0 dB Max |
2.0:1 |
20 W (Peak) |
LM-500M8G-2-33DBM- 12V-OPT2G4G |
Active |
2 GHz |
4 GHz |
2.0 dB max |
2.0:1 max |
+33dBm CW max. |
LM-618-10-1W-SHS-1-F |
Preliminary |
6 GHz |
18 GHz |
2.0 dB max., 1.5 dB typ. |
2.0:1 max |
1 W CW, 100 W Peak, 1 us |
Pulse, 0.1% Duty Cycle Derated to 20% at 125°C |
LM-80M600M-C3-1 |
Active |
0.08 GHz |
0.6 GHz |
1.2 dB max |
1.5:1 max |
5 Watts CW @ +25ºC (Peak) |
LM-8G18G-7-33DBM- 12V |
Active |
8 GHz |
18 GHz |
2.0 dB max |
2.0:1 max |
+33dBm CW max. |
LM-0518-10-1W-SHS-2- FM |
Preliminary |
0.5 GHz |
18 GHz |
2.0dB max., 1.5dB typ. |
2.0:1 max |
12 W max. |
LM-0518-10-1W-SHS-2- FM-OPT12 |
Preliminary |
0.5 GHz |
18 GHz |
2.0dB max., 1.5dB typ. |
2.0:1 max |
12 W max. |
LM-0518-10-1W-SHS-2- M |
Active |
0.5 GHz |
18 GHz |
2.0dB max., 1.5dB typ. |
2.0:1 max |
100 W (Peak) |
LM-12-20-5W-2-M |
Preliminary |
1 GHz |
2 GHz |
1.0 dB Max |
2.0:1 |
4 Watts |
LM-1G2G-4CW-1KWP- SMF-OPT2G4G |
Active |
2 GHz |
4 GHz |
1.2 dB Max |
2.0:1 Max |
40 W CW (46 dBm) |
LM-218-10-300PW- SHS-2 |
Active |
2 GHz |
18 GHz |
2.5 dB Maximum |
2.0:1 |
+10 dBm |
LM-2G18G-2D8-33DBM- 12V |
Active |
2 GHz |
18 GHz |
2.0 dB max |
2.0:1 max |
+33dBm CW max. |
LM-30M8G-0DB- 33DBM-12V |
Preliminary |
0.03 GHz |
8.0 GHz |
2.0 dB |
2.0:1 max |
+33 dBm CW max. |
LM-30M8G-2DB- 33DBM-12V |
Preliminary |
0.03 GHz |
8 GHz |
2.0 dB max |
2.0:1 max |
+33 dBm CW max. |
LM-3R15G3R25G-1- PE2-HERM |
Preliminary |
3.15 GHz |
3.25 GHz |
1.0 dB max. @ =-20 dBm |
- |
- |
LM-400M4G-20CW- 220WP-SMF |
Preliminary |
0.4 GHz |
4.0 GHz |
1.2 dB typ |
1.5:1 typ |
20 W CW |
LM-618-10-1W-SHS-1-M |
Active |
6 GHz |
18 GHz |
2.0 dB Max, 1.5 dB Typ |
2.0:1 max |
1 W CW, 100 W Peak, 1 us |
Pulse, 0.1% Duty Cycle Derated to 20% at 125°C |
LM-6D7G7D9G-30W- SFF-OPT812 |
Preliminary |
8 GHz |
12 GHz |
1.8 dB max. |
1.8:1 max |
50 W min. |
LM-80M600M-C3-1- OPTSFM |
Preliminary |
0.08 GHz |
0.6 GHz |
1.2 dB max. |
1.5:1 max. |
5 Watts CW @ +25ºC (Peak) |
LM-0118-10-1W-SHS-2- M |
Active |
0.1 GHz |
18 GHz |
2.0dB max, 1.5dB typ |
2.0:1 max |
100 W Peak |
LM-161605-10W1-HPR |
Active |
16 GHz |
16.5 GHz |
1.5 dB Max |
17dB typ |
160W peak, 40W Average |
LM-26G40G-14-20W- 292FF |
Active |
26.5 GHz |
40 GHz |
4.0 dB Max |
2.0:1 |
20 W (Peak) |
LM-26G40G-14-20W- 292FM |
Active |
26.5 GHz |
40 GHz |
4.0 dB Max |
2.0:1 |
20 W |
LM-30M3G-C3-1 |
Active |
0.03 GHz |
3 GHz |
1.2 dB Max |
1.5:1 Max |
5 W CW @ +25°C (Peak) |
LM-32D5G33D5G-14- 20W-292FF |
Preliminary |
32.5 GHz |
33.5GHz |
4.0 dB Max |
2.0:1 |
20 W (Peak) |
LM-32G36G-14-20W- SMT |
Active |
32 GHz |
36 GHz |
2.0 dB Max |
2.0:1 |
20 W (Peak) |
LM-500M8G-12- 33DBM-12V |
Active |
0.5 GHz |
8 GHz |
2.0 dB max. |
2.0:1 max |
+33 dBm CW max. |
LM-500M8G-2-33DBM- 12V |
Active |
0.5 GHz |
8 GHz |
2.0 dB Max |
2.0:1 Max |
+33 dBm CW Max |
LM-0518-10-1W-SHS-1- SMF |
Active |
0.5 GHz |
18.0 GHz |
2.0 dB |
2.0:1 max |
1 Watt CW, 100 Watts |
LM-0518-10-1W-SHS-2- F |
Active |
0.5 GHz |
18 GHz |
2.0 dB Max, 1.5 dB Typ |
2.0:1 max |
100 W (Peak) |
LM-1G2G-4CW-1KWP- SFF |
Preliminary |
1 GHz |
2 GHz |
0.7 dB Max |
2.0:1 Max @ -10 dBm Input |
4 W CW Min, 1 kW Peak (1% Duty Cycle, 1 µs Max Pulse Width) |
LM-20M80M-10-20W |
Active |
0.025 GHz |
0.08 GHz |
1.5dB max, 0.5dB typ |
2.0:1 max |
CW In-Band 5 to 10 Watts, CW Out of Band 20 Watts max |
LM-218-14-200W-SMF- HERM * |
Active |
2 GHz |
18 GHz |
2.0 dB Maximum |
2.0:1 max |
1 W CW |
LM-2G8G-13-5W-SFF * |
Active |
2 GHz |
8 GHz |
1 dB Typ |
2.0:1 max |
5 Watts CW Max |
LM-30M3G-C3-1-PE2- HERM |
Active |
0.03 GHz |
3.0 GHz |
1.2 dB |
1.5:1 Max |
5 W CW @ +25 °C (Peak) |
LM-0518-10-1W-SHS-1- M |
Active |
0.5 GHz |
18 GHz |
2.0 dB Max, 1.5 dB Typ |
2.0:1 max |
1 Watt CW, 100 Watts |
LM-1G18G-15-25W- SMF |
Active |
1 GHz |
18 GHz |
2.5 dB Max |
2.0:1 max |
25 Watts CW Max |
LM-26G40G-14-20W- 292MM |
Active |
26.5 GHz |
40 GHz |
4.0 dB Max |
2.0:1 |
20 W (Peak) |
LM-500M8G-5-33DBM- 12V |
Active |
0.5 GHz |
8.0 GHz |
2.0 dB |
2.0:1 max |
+33 dBm CW max. |
LM-6D7G7D9G-30W- SFF |
Active |
6.7 GHz |
7.9 GHz |
1.1 dB Max |
1.5:1 max |
30 Watts CW Max - See Graph |
LM-218-14-200W-SMF- OPT10M18G |
Active |
0.01 GHz |
18 GHz |
2.0 dB max. |
2.0:1 max |
1 Watt CW |
LM-0518-10-1W-SHS-1- SFM |
Active |
0.5 GHz |
18.0 GHz |
2.0 dB |
2.0:1 max |
1 Watt CW, 100 Watts |
LM-18G40G-SMT-1 |
Active |
18 GHz |
40 GHz |
4.0 dB Max |
2.0:1 |
2 W |
LM-100M20G-18-10W- SFF |
Active |
0.1 GHz |
20 GHz |
2 dB Max |
2.0:1 Max |
10 W Pulsed, 100 us Pulse |
Width, 10% Duty Cycle, 1 W CW |
LM-1G2G-4CW-1KWP- SMF |
Active |
1 GHz |
2 GHz |
0.7 dB Max |
2.0:1 Max |
4 W CW Max, |
1 kW Peak (1% Duty Cycle, 1 µs Max Pulse Width) |
LM-1M500M-C3-1 |
Active |
0.001 GHz |
0.5 GHz |
0.9 dB Max |
1.5:1 max |
100 W, 1 us Pulse Width, 1% Duty Cycle or 2 W CW @ +25°C |
LM-2G18G-10-1W-SHS- 1-M |
Active |
2.0 GHz |
18.0 GHz |
2.0 dB |
2.0:1 max |
1 W CW, 100 W Peak, 1 us |
Pulse, 0.1% Duty Cycle Derated to 20% at 125°C |
LM-10M2D5G-100CW- 1KWP-TNCFM |
Preliminary |
0.01 GHz |
2.5 GHz |
0.5 dB Typ |
1.3:1 max (@ -10 dBm input) |
100 watts CW Max (Notes 1,2), 1 kW peak (1% duty cycle, 1 µs Max pulse width) (Notes 1, 2, 3) |
LM-10M2D5G-100CW- 1KWP-TNCFM-HERM |
Preliminary |
0.01 GHz |
2.5 GHz |
0.5 dB Typ |
1.3:1 max (@ -10 dBm input) |
100 watts CW Max (Notes 1,2), 1 kW peak (1% duty cycle, 1 µs Max pulse width) (Notes 1, 2, 3) |
LM-18G40G-18-1W- 292FF * |
Active |
18 GHz |
40 GHz |
4.0 dB Max |
2.1:1 |
1 Watt CW Max |
LM-1G18G-15-25W-SFF |
Active |
1 GHz |
18 GHz |
2.5 dB Max |
2.0:1 max |
25 W CW Max - Measured 45 dBm (31.6 W) |
LM-400M2G-20-1W-SFF |
Active |
0.4 GHz |
2.0 GHz |
0.7 dB Max - Measured 0.69 dB |
2.0:1 Max |
1 W CW Max |
3 W Peak Max (1 µs pulse width, 0.1% duty cycle) |
LM-0518-10-1W-SHS-2- M-1218 * |
Active |
12 GHz |
18 GHz |
2.0 dB Max, 1.5 dB Typ |
2.0:1 Max |
100 W (Peak) |
PLA-14D65G15G35G- 20DB-SFF-250W |
Active |
14.65 GHz |
15.35 GHz |
3.59 dB Max |
2.0:1 Max |
125 Watts Peak having a pulse width of 40 µs and an average power of 12.5 Watts |
LM-100M20G-18-10W- SFF-MAH |
Active |
0.1 GHz |
20.0 GHz |
3 dB Max |
2.0:1 Max |
10 W Pulsed, 100 µs Pulse |
Width, 10% Duty Cycle, 1 W CW |
LM-6G18G-15-10W-SFF |
Active |
6 GHz |
18 GHz |
2.5 dB Typ @ 0 dBm |
1.8:1 |
10 W CW (Peak) |
* |
LM-10M2D5G-100CW- 1KWP-SFF |
Active |
0.01 GHz |
2.5 GHz |
0.5 dB Typ |
1.3:1 Max |
100 watts CW Max (Notes 1, |
2), |
1 kW peak (1% duty cycle, 1 µs Max pulse width) (Notes |
1, 2, 3) |
LM-0518-10-1W-SHS-1- |
Active |
0.5 GHz |
18 GHz |
2.0 dB Max, 1.5 dB Typ |
2.0:1 Max |
1 Watt CW, 100 Watts Peak, 1 µs Pulse, |
F * |
0.1% Duty Cycle, Derated to 20% at 125 ºC |
LM-1G18G-15-3W- 500WP-SFF |
Active |
1.0 GHz |
18.0 GHz |
2.5 dB |
2.0:1 Max |
3 W CW |
LM-1G18G-16-4W-SMF |
Active |
1.0 GHz |
18.0 GHz |
2.3 dB |
2.0:1 Max |
4W CW, 100W Peak (1 us |
Pulse Width, 0.1% Duty Cycle) |
