| System |
| CPU |
Ampere® Altra® Q32 17 SoC 32 cores, 1.7 GHz, 45 W TDP, Option Ampere Altra Q64 and Ampere Altra Max M128 |
| Memory type |
16x DIMM sockets with individual memory channels |
| Up to 4TB (16 x 256 GB) DDR4 RDIMM memory, up to 3200 MT/s |
| GPU |
| Graphics Card |
RTX MXM A 500 (2048 CUDA Cores) |
| Storage |
|
| SSD |
TBD |
| Ethernet |
| Ethernet |
2x 1 Gigabit Ethernet with RJ45 |
| 2 x 10G SFP+ |
| Side I/O |
|
| GLAN |
2 |
| 10 GbE SFP+ |
2 |
| COM |
1 |
| CAN |
2 |
| USB3.0 |
4 |
| DP |
4 |
| VGA |
1 |
| DC-IN |
1 |
| Power Requirement |
1 x Power Button with LED backlight |
| OS support list |
| OS |
Linux RedHat ,Ubuntu |
| Power Requirement |
28V DC IN (18V 36V) |
| Dimension |
TBD |
| Weight |
10 KG |
| Operating Temp. |
0 C to 60°C |
| Storage Temp. |
-40°C to 85°C |
| Relative Humidity |
5% to 95%, non condensing |
| Environmental |
| MIL-STD-810 Test |
Method 500.5, Procedures I and II (Altitude, Operation): |
| 12,192M, (40,000 ft) for the initial cabin altitude (18.8Kpa or 2.73 Psia) |
| Method 500.5, Procedures III and IV (Altitude, Non-Operation): |
| 15,240, (50,000 ft) for the initial cabin altitude (14.9Kpa or 2.16 Psia) |
| Method 501.5, Procedure I (Storage/High Temperature) |
| Method 501.5, Procedure II (Operation/High Temperature) |
| Method 502.5, Procedure I (Storage/Low Temperature) |
| Method 502.5, Procedure II (Operation/Low Temperature) |
| Method 503.5, Procedure I (Temperature shock) |
| Method 507.5, Procedure II (Temperature & Humidity) |
| Method 509.7 Salt Spray (50±5)g/L |
| Method 514.6, Vibration Category 24/Non-Operating (Category 20 & 24,Vibration) |
| Method 514.6, Vibration Category 20/Operating (Category 20 & 24,Vibration) |
| Method 516.6, Shock-Procedure V Non-Operating (Mechanical Shock) |
| Method 516.6, Shock-Procedure I Operating (Mechanical Shock) |
| Reliability |
Conduction Cooling. |
| Designed & Manufactured using ISO 9001 Certified Quality Program. |
| EMC |
EN 61000-4-2: Air discharge: 8 kV, Contact discharge: 6kV |
| EN 61000-4-3: 10V/m |
| EN 61000-4-4: Signal and DC-Net: 1 kV |
| EN 61000-4-5: Leads vs. ground potential 1kV, Signal und DC-Net: 0.5 kV |
